Description

The UT-series is a 2-pole motor, compact and economical type submersible pump equipped with a vortex impeller for sewage and wastewater. the UTZ-series is an automatic model equipped with a simple float switch that prevents dry-running operation and reduces power consumption.



TECHNICAL DATA

  • Outlet (BSPF): 1½” – 2″
  • Motor output (kW): 0.25 – 0.75
  • Max head (m): 6.5 – 12.5
  • Phases: 1 & 3
  • Max flow (I/min): 230 – 440
  • Free passage (mm): 35
SLOPE PROTECTION

PERFORMANCE CURVE

UT_UTZ_50hz

SPECIFICATIONS

PUMP:

Handle: Resin

Outlet: Grey cast iron

Pump casing & stand: Grey cast iron

Impeller: GFRP

Shaft: S/S 403

Shaft seal: Silicon carbide

Lubrication: Oil

Level switch: Polypropylene

UT and UTZ Series are compact and economical, heavy-duty submersible pumps with a vortex impeller for sewage and wastewater applications. These pumps feature a wide 35 mm large solids passage with a semi-vortex design that reduces clogging of fibrous matter to a minimum. Moreover, these pumps are loaded with field-tested and proven Tsurumi technologies including an anti-wicking cable, dual inside mechanical seals with silicon carbide face and Oil Lifter. And, these pumps come with resin guide rail fitting device that enables easy installation and maintenance. The UTZ-series pumps are automatic models equipped with a simple float switch that prevents dry-running operation and reduces power consumption. All Tsurumi pumps are designed and built to deliver the high degree of reliability, durability and quality required for continuous duty.
